Pentair WellMate WM-23 Quick Connect 80 Gallon Fiberglass Well Tank

WellMate Pentair WM-23 Quick Connect 80 Gallon Fiberglass Well Tank

Reliable. Durable. Maintenance-Free.

The WellMate WM-23 Quick Connect 80-Gallon Fiberglass Well Tank is the smart choice for homeowners and contractors seeking long-lasting performance, corrosion resistance, and easy installation. Designed with a pre-pressurized air cell and patented quick connect system, this tank delivers outstanding water pressure and storage capacity without the hassle of steel tank maintenance.

Key Features:

• Capacity: 80 gallons total volume (30.1 gallons drawdown at 40/60 PSI)

• Material: Corrosion-proof, non-metallic fiberglass construction

• Design: Seamless, molded shell eliminates rust, dents, and flaking paint

• Quick Connect System: Makes installation faster, safer, and more reliable

• Bladder-Free AIr Cell Operation: Patented Air Cell is replaceable and eliminates the risk of bladder /tank failure—ideal for long-term performance

• Lightweight & Easy to Handle: Weighs less than steel tanks of comparable size

• NSF Certified: Safe for potable water systems

• Pentair Factory Warranty: All Tanks come with a Pentair 5 Year Warranty from the date of Installation. (See Photos for Details.)

Specifications:

• Model: WM-23 QC

• Max Operating Pressure: 100 PSI

• Height: Approx. 62.5"

• Diameter: Approx. 21"

• Connection Size: 1-1/4" NPT Quick Connect Nipple

Whether you're upgrading an old system or building new, the WellMate WM-23 provides dependable water storage without the worry of rust or corrosion. It's a maintenance-free solution designed to last—and backed by the trusted Pentair name.

Please note: Google has a note that the shipping on the tank is free on the main google listing.  Unfortunately this is incorrect and Google will not fix it. We charge a $150.00 flat rate shipping charge for the first tank and $ 100.00 charge per additional tank. If you are purchasing more than 4 tanks please contact us for discounted shipping.  We also offer Free local pick up at our warehouse in Waterford MI.

P.S. Installing this tank yourself? Check out our custom Quick Connect Tank Tees, these will save you time and money!

Note:   Tanks are shipped with a small holding charge, and will need to be charged up to 2psi below the cut in point of your well pump pressure switch. (Example 30 - 50 psi well pump pressure switch = pressure tank to 28psi before installation.)
